Triumph OEM Handguards Kit - A9630315
Product Details
MPN: A9630315
Brand: Triumph
FITMENT
MPN A9630315 Model Fitment
Will it fit my Triumph? Fitment is identified by the last six characters of your VIN. Letters rank above numbers.
- TF250-CAll VINs
- TF250-EUp to CV1239
- TF450-CAll VINs
- TF450-EUp to CW1884
Fitment is from Triumph's parts catalogue. Confirm against your VIN before ordering. Request fitment verification.
WHAT'S IN THE BOX
| NO. | DESCRIPTION | QTY |
|---|---|---|
| 1 | Handguard panel, right side | 1 |
| 2 | Handguard panel, left side | 1 |
| 3 | Screw, Torx | 4 |
| 4 | Frame, left | 1 |
| 5 | Frame, right | 1 |
| 6 | Clamp, front | 2 |
| 7 | Clamp, rear | 2 |
| 8 | Fastener, M8 x 0.79 in (20 mm) | 2 |
| 9 | Fastener, M6 x 0.79 in (20 mm) | 4 |
| 10 | Expansion plug | 2 |
| 11 | Wedge nut | 2 |
| 12 | Fastener, M8 x 1.77 in (45 mm) | 2 |
| 13 | Pivot bolt, shouldered | 1 |
| 14 | Lock nut | 2 |
| 15 | Sleeve | 1 |
| 16 | Pivot bolt | 1 |
From Triumph's fitting instructions, updated June 2025.
INSTALLATION INSTRUCTIONS
Triumph fitting instructions for A9630315 (PDF), updated June 2025.
Bought it online? Our service team will fit it for you. Request a service appointment.
